P75/76 Pump Performance Data
|
Flow ml/rev |
G.W |
Rated Pressure |
Max pressure |
speed |
Input Power KW |
|
67.19 |
1＂ |
20.7 |
24.2 |
2400/600 |
64 |
|
83.99 |
1 1/4＂ |
20.7 |
24.2 |
2400/600 |
79.5 |
|
100.78 |
1 1/2＂ |
20.7 |
24.2 |
2400/600 |
95 |
|
117.58 |
1 3/4＂ |
20.7 |
24.2 |
2400/600 |
110.5 |
|
134.37 |
2＂ |
17.2 |
20.7 |
2400/600 |
105 |
|
151.18 |
2 1/4＂ |
17.2 |
20.7 |
2400/600 |
118 |
|
167.97 |
2 1/2＂ |
17.2 |
20.7 |
2400/600 |
132 |
|
184.77 |
2 3/4＂ |
13.8 |
17.2 |
2400/600 |
116 |
|
201.56 |
3＂ |
13.8 |
17.2 |
2400/600 |
126 |
M75/76 Motor Performance Data
|
Flow |
Input flow |
G.W |
Rated Pressure |
Max Pressure |
Speed |
Output Power |
Output Torque |
|
67.19 |
157 |
1＂ |
20.7 |
24.2 |
2200/600 |
43.5 |
207.8 |
|
100.78 |
223 |
1 1/2＂ |
20.7 |
24.2 |
2200/600 |
61.8 |
295.2 |
|
134.37 |
295 |
2＂ |
17.2 |
20.7 |
2200/600 |
68 |
324.8 |
|
167.97 |
365 |
2 1/2＂ |
17.2 |
20.7 |
2200/600 |
84.5 |
403.7 |
|
201.56 |
431 |
3＂ |
13.8 |
17.2 |
2200/600 |
81.5 |
387 |
P75/76 M75/76 Gear Pump Model Number
Item Model Code/Part Number
1 M75A978BEOL30-7* 3169310003
2 M76A878BEOF22-7 3169718051
3 M76A878BEOR22-7 3169718009
4 M76C878BE*SV*17-11 3169710074
5 P75A-2.75 H5883 ** 3169310225
6 P75A178*BEOP20-7 3169310107
7 P75A278*BEON25-7 3169310137
8 P75A278BEOM17-7 3169112209
9 P75A278BEOS20-7 3169112206
10 P75A298BEON17-7 H6514 3169112408
11 P75B278BIOS20-7DOG10-1 3169122209
12 P75B278LOOS22-7/P30A292FEAB07- 3169520085
13 P75B298BION*20-7B*OM*15-1 3169320389
14 P76A478BEOP22-7 3169614059
15 P76A578BEON22-7 3169615006
16 P76B-1.5(4X) H5883 3169640038
17 P76B278*BION17-7D.H5883 3169620105
18 P76B278*BIOT27-7D* H5883 3169630037
19 P76B278LOON17-7/P31A292FEAB07- 3169520059
